| 型号 | H | H1 | H2 | A | B | J1 | J2 | J3 | L | L1 | D | E | M | L1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CPDS20S CPDS20S-04 |
30 | - | 4 | 54.9 | 20 | 21.9 | 9.5 | 44.75 | 60 | 39 | 4.5 | 5.28 | M5 | 6.5 |
| CPDS25S CPDS25S-04 |
36 | 40 | 5.5 | 61.4 | 23 | 23.9 | 9.5 | 44.75 | 60 | 39 | 4.5 | 8.2 | M5 | 6.5 |
注：H11为钳制器与AN/HAN滑块配套使用加装安装垫板后的高度。
